Geneva driver wheel
CADlingo generated this model from the prompt below. Open it in the studio to inspect it in 3D, view sections and try its dimension controls.
The prompt
Geneva mechanism driver wheel. Disc diameter 80mm, thickness 10mm. Driving pin 6mm diameter at 30mm radius. Crescent locking arc matching 50mm Geneva wheel. Shaft bore 12mm with D-flat. Hub 25mm diameter, 20mm below disc. Balance hole opposite pin.
Model facts
- Overall size
- 74.8 × 80 × 45 mm
- Bodies
- 1
- Volume
- 52.9 cm³
- Adjustable in the studio
- 3 dimensions
