Straight bevel gear with flange
CADlingo generated this model from the prompt below. Open it in the studio to inspect it in 3D, view sections and try its dimension controls.
The prompt
Bevel gear with straight teeth. Pitch cone angle 45 degrees, 20 teeth, module 3mm. Face width 20mm. Shaft bore 15mm with set screw. Hub diameter 30mm, length 25mm. Mounting flange with 4 M4 holes on 40mm PCD.
Model facts
- Overall size
- 64.2 × 64.2 × 48.8 mm
- Bodies
- 1
- Volume
- 55.1 cm³
- Adjustable in the studio
- 4 dimensions
