Mirrored T bracket
CADlingo generated this model from the prompt below. Open it in the studio to inspect it in 3D, view sections and try its dimension controls.
The prompt
Create L-bracket 80x30x50mm. Mirror on YZ plane to create symmetric T-bracket. Add 6mm bolt holes on both sides.
Model facts
- Overall size
- 160 × 30 × 50 mm
- Bodies
- 1
- Volume
- 43.6 cm³
- Adjustable in the studio
- 4 dimensions
