Bolted flange
CADlingo generated this model from the prompt below. Open it in the studio to inspect it in 3D, view sections and try its dimension controls.
The prompt
Design a circular flange. Outer diameter 120mm, thickness 15mm, center hole 50mm. 6 bolt holes (8mm) on BCD 100mm.
Model facts
- Overall size
- 120 × 120 × 15 mm
- Bodies
- 1
- Volume
- 135.7 cm³
- Adjustable in the studio
- 3 dimensions
