Compression spring
CADlingo generated this model from the prompt below. Open it in the studio to inspect it in 3D, view sections and try its dimension controls.
The prompt
Design compression spring. Outer diameter 20mm, wire 2mm, height 40mm, 8 turns. Use helix sweep.
Model facts
- Overall size
- 20 × 20 × 40 mm
- Bodies
- 1
- Volume
- 1.4 cm³
- Adjustable in the studio
- 4 dimensions
