90° swept elbow pipe
CADlingo generated this model from the prompt below. Open it in the studio to inspect it in 3D, view sections and try its dimension controls.
The prompt
Design 90° elbow pipe. Outer diameter 30mm, inner 24mm. Path: 50mm vertical, R30 curve, 50mm horizontal. Use Sweep.
Model facts
- Overall size
- 95 × 30 × 95 mm
- Bodies
- 1
- Volume
- 37.4 cm³
- Adjustable in the studio
- 3 dimensions
