Compressor blisk, 24 blades
CADlingo generated this model from the prompt below. Open it in the studio to inspect it in 3D, view sections and try its dimension controls.
The prompt
Design a gas turbine compressor blisk (bladed integrated disk). OD 300mm, bore 80mm. Hub 140mm diameter, 50mm thick. 24 integral blades 40mm height, 30mm chord, 35° stagger. 3 labyrinth seal teeth in bore. 8 bolt holes M8 on 110mm PCD. 8 lightening holes.
Model facts
- Overall size
- 300 × 300 × 50 mm
- Bodies
- 1
- Volume
- 1621.3 cm³
- Adjustable in the studio
- 3 dimensions
