M8 wing nut
CADlingo generated this model from the prompt below. Open it in the studio to inspect it in 3D, view sections and try its dimension controls.
The prompt
Design a wing nut for hand tightening. M8 thread. Central body diameter 12mm, height 10mm. Two symmetrical wings spanning 40mm tip-to-tip. Wing height 14mm, thickness 3mm. Through bore.
Model facts
- Overall size
- 40 × 12 × 14 mm
- Bodies
- 1
- Volume
- 1.8 cm³
- Adjustable in the studio
- 2 dimensions
